Apple Grading Machines
Type I. (Cap: 200-225 boxes of 20 kg/8 Hr.)
Brushing Section: The brusher is fitted with nylon bristle rollers or soft horse hair rollers rotating on their own axis. The products will be let onto the bristle rollers manually. The apples got polished while moving on the rotating brushes. Fans are provided top on the brushes to remove moisture on apple if any.
Length: 1300 mm.
Width: 550 mm of roller
Power: 1 H.P, 3 Ph
No of Rollers: 12 (7 Green + 5 Black)
Size Grader ( 1 LANE, 6 GRADE ): Rollers and other contact parts are fabricated from materials which are recommended for food processing equipment. Structure of mild steel. This is a roller type grader, with openings between the rollers. The openings increase gradually towards the discharge side. Products are graded according to their diameter. There will be provision for adjust the gap to grade different products.
Power: 1 HP
Control Panel: The control panel withmotor starter and main switch, helps in proper electrical synchronization and control of all the machines from a single place. All the machines can be switch On or Off from a single place by a single person. Fire resistant wire will be used with standard colour coding. Speed various is also available in the machine.
Total Power Consumption: 2 HP
Type II. (Cap: 300-350 boxes of 20 kg / 8 Hr.)
Brushing Section: The brusher is fitted with nylon bristle rollers or soft horse hair rollers rotating on their own axis. The products will be let onto the bristle rollers manually. The apples got polished while moving on the rotating brushes. Fans are provided top on the brushes to remove moisture on apple if any.
Length: 2300 mm.
Width: 550 mm of roller
Power: 1 H.P, 3 Ph
No of Rollers: 22 (11 Green + 11 Black)
Size Grader ( 1 LANE, 6 GRADE ): Rollers and other contact parts are fabricated from materials which are recommended for food processing equipment. Structure of mild steel. This is a roller type grader, with openings between the rollers. The openings increase gradually towards the discharge side. Products are graded according to their diameter. There will be provision for adjust the gap to grade different products.
Power: 1 HP
Control Panel: The control panel withmotor starter and main switch, helps in proper electrical synchronization and control of all the machines from a single place. All the machines can be switch On or Off from a single place by a single person. Fire resistant wire will be used with standard colour coding. Speed various is also available in the machine.
Total Power Consumption: 3 HP
Type III (Cap: 600-650 boxes of 20 kg / 8 Hr.)
Brushing Section: The brusher is fitted with nylon bristle rollers or soft horse hair rollers rotating on their own axis equipped with High Quality bearing (SKF).The products will be let onto the bristle rollers manually. The apples got polished while moving on the rotating brushes. Fans are provided top on the brushes to remove moisture on apple if any. Fabricated with MS Square Pipe Structure & Heavy Duty GI Sheet.
Length: 3000 mm.
Width: 850 mm of roller
Power: 1 H.P, 3 Ph
No of Rollers: 22 (11 Green + 11 Black)
Size Grader ( 2 LANE, 6 GRADE ): Rollers and other contact parts are fabricated from materials which are recommended for food processing equipment. Structure of mild steel. This is a roller type grader, with openings between the rollers. The openings increase gradually towards the discharge side. Products are graded according to their diameter. There will be provision for adjust the gap to grade different products.
Power: 2 HP
Control Panel: The control panel withmotor starter and main switch, helps in proper electrical synchronization and control of all the machines from a single place. All the machines can be switch On or Off from a single place by a single person. Fire resistant wire will be used with standard colour coding. VFD Speed Control
Total Power Consumption: 3.5 HP
